COLDWING 12

COLDWING 12 is an advanced 120mm fan with eye-catching yellow blades. It provides high airflow to cool down even the hottest systems.

Its solid structure minimizes operational vibrations so as to maintain the lowest possible noise level. The integrated auto shut-down & restart function protects the fan from the damage of sudden electric surges.

11-Blade

Design

The Design guarantees Higher Airflow (CFM) at low Speed (RPM).

SPECIFICATIONS

Fan Dimension:

Bearing Type:

MTTF:

Voltage:

Weight:

Function:

(W)120 x (H)120 x (D)25mm

Sleeve Bearing

30.000hrs

12V

155g

Auto Shutdown & Restart

Product Number

RY1225S12B-R

RM1225S20B

RY1225S15B-RP

Fan Speed

(RPM)

1200

2000

300~1500

Air Flow

(CFM)

51.2

106.7

22.1~66.3

Static Pressure

(inch H2O)

0.041

0.114

0.007~0.065

Noise Level

(dBA)

24.9

36.6

6.5~30.4

Current

(A)

0.20

0.38

0.23

Include 3-pin to 4-pin Molex adaptor cable.
